Mercury 5hp Outboard 5MXLH
$1,023.00
The Mercury 5hp Outboard 5MXLH is a compact 5hp four-stroke outboard with a 25” X-Long shaft, designed for boats with higher transoms. Featuring smooth throttle response, simple tiller steering, and lightweight construction, it delivers dependable performance for a wide range of small boats.
| Product Condition |
New |
|---|
In stock
The Mercury 5hp Outboard 5MXLH offers dependable four-stroke performance in a compact, easy-to-handle design with a 25-inch X-Long shaft. Built for boats with taller transoms, this outboard provides smooth acceleration, responsive handling, and simple operation—making it ideal for utility boats, sailboats, and specialized small-craft applications.
Features and Performance
Powered by a 123cc single-cylinder four-stroke engine, the 5MXLH delivers consistent power across a 4,500–5,500 RPM operating range. The carbureted fuel system ensures reliable fuel delivery, while manual starting keeps the design simple and easy to maintain.
The tiller steering provides direct control, ideal for precise maneuvering at low speeds. An internal 0.3-gallon fuel tank keeps the setup compact and hose-free, while the integrated carry handle makes transport and installation straightforward.
Why You Should Buy It
If your boat requires a 25” X-Long shaft and you want a reliable, lightweight outboard with proven four-stroke efficiency, the Mercury 5MXLH is an excellent choice. It combines portability, simple operation, and the trusted engineering of Mercury Marine—perfect for small boats, sailboats, and backup propulsion.
FAQ – Mercury 5hp Outboard 5MXLH
Q: What boats are suitable for the Mercury 5MXLH?
A: Boats with higher transoms such as sailboats, utility boats, and specialized small craft.
Q: What is the benefit of the 25” X-Long shaft?
A: It ensures proper propeller depth and improved control on boats with tall transoms.
Q: Is this outboard easy to transport?
A: Yes. At 60 lbs with an integrated carry handle, it remains manageable and portable.
Q: What warranty is included?
A: The engine is covered by a Mercury Marine 3-Year Warranty.
| Specification | Details |
|---|---|
| Engine Type | Mercury 5MXLH Inline 1 Four Stroke |
| Horsepower | 5 hp |
| Cylinders | 1 Cylinder |
| Displacement | 123 cc |
| Fuel System | Carbureted |
| Induction System | 2-valve, pushrod |
| Shaft Length | 25” (X-Long) |
| Steering | Tiller |
| Starting System | Manual |
| Full Throttle RPM Range | 4,500 – 5,500 rpm |
| Weight | 60 lbs |
| Propeller | 7.4” x 7.0” 3-Blade Composite |
| Fuel Tank | Internal (0.3 gallons) |
| Warranty | Mercury Marine 3-Year Warranty |
Mercury 5MXLH Outboard Motor
3-blade composite propeller
Internal fuel tank (0.3 gallons)
Integrated carry handle
Service tool kit & parts
Stop switch lanyard
Owner’s manual
